Construction Description
1. Main body: The fuselage is an independent rectangular cylinder, which is connected with the powder hopper with a closed bearing seat, and the powder hopper extends to the outside of the body, and the V-shaped chassis is installed under it, and the ground is wide and flat, so it must be installed and can be placed indoors at will.
2. Particle manufacturing device: the rotating drum is horizontally placed below the powder hopper, there are bearing bearings before and after, it is driven by the rack, and the front bearing cover of the end face is movable, when assembling and dismantling, as long as a wing nut is rotated, the bearing cover and the rotating drum can be extracted, and the two ends of the drum are made with convex square rings, which are embedded in the bearing chamber, so that the oil can not penetrate into the powder and not be plugged by bonding.
3. Reducer: worm gear drive, speed ratio to 1:12, oil can be stored in the box to ensure good gear lubrication and no noise, there is a sight glass on the box to observe, observe the operation and oil storage, the outer end of the worm gear, equipped with an eccentric shaft, drive the rack for reciprocating motion.
Description of the role
1. How to use: start the machine, pour the mixture into the bucket, by the swinging action of the rotating drum, form particles through the wire screen, and fall into the container.
2. Precautions: If the powder in the powder hopper is stagnant, do not shovel by hand, so as not to cause injury accidents, and use bamboo shovel or stop work.
Lubrication of parts
1. The box part of the machine is equipped with an oil gauge, which should be refueled once before driving, and can be added according to the temperature rise and operation of each bearing on the way.
2. The worm gear box must be stored for a long time, and the oil level height is that the worm gear is all invaded into the oil, if it is often used, it must be replaced with new oil every three months, and there is an oil plug at the bottom of the coffin, which can be used for oil discharge.
3. When refueling the machine, do not let the oil overflow out of the cup, let alone flow to the surroundings of the machine and the ground. Because oil is easy to pollute the material and affect the quality of the product.
Care instructions
1. Regularly inspect the parts, once a month, check whether the worm gear, worm, bolts, bearings and other moving parts on the lubrication block are flexible and worn, and the defects should be repaired in time and should not be used reluctantly.
2. The machine should be used in a dry and clean room, and should not be used in places where the atmosphere contains acids and other corrosive gases to the body.
3. After the machine is used or stopped, the rotating drum should be taken out for cleaning and brushing the remaining powder in the bucket, and then installed it properly to prepare for the next use.
4. When the drum moves back and forth during the work, please adjust the M10 screw on the front bearing to the appropriate position. If the gear shaft is moving, please adjust the M10 screw behind the bearing frame to the appropriate position, adjust the clearance to the bearing without sound, hand turn the pulley, the appropriate tightness is appropriate, too tight or too loose can make the machine damaged.
5. If the machine is out of service for a long time, the whole body of the machine must be wiped clean, and the smooth surface of the parts must be coated with anti-rust oil and covered with a cloth canopy.
Installation instructions
1. This machine is packed as a whole, and after unpacking, it is moved to an appropriate place for use, and it can be used after being flattened.
2. The device of the electrical circuit: pay attention to the direction of rotation and do not reverse it, because one end of the worm has a plane ball bearing, and the direction of force must be on the bearing, otherwise the other end of the worm will be damaged and heated, affecting the service life of the parts.
